Overview:
The Alpha Front Bumper DIY Kit for 1st Gen Tacomas delivers aggressive styling and full-width protection in a weld-together package. Featuring dedicated lighting mounts and an enclosed design, it’s ideal for off-road builds that don’t require a winch.
– Tabbed/slotted design ensures fast and precise DIY assembly
– Fully enclosed steel construction with integrated light mounts
– Precision-cut opening for 22" LED light bar and 2.5" fog lights
– Built-in shackle mounts reinforced with DOM tubing
– Adjustable fitment with included hardware and Tacoma-specific spacers
Specifications:
– Frame mount, support plates, wings: 3/16" HRPO steel
– Vertical plates: 1/4" steel
– Shackle brackets: 3/8" steel + 1.5" OD .250 wall DOM
– Panels: 11-gauge HRPO steel
– Tubing: 1.75" OD 11-gauge ERW steel
– Light bar cutout: Fits Extreme LED 22" X6 10W
– Fog light openings: 2.5" diameter (forward oval)
– Weight: ~80 lbs (plus optional grille guard tubing)
Fitment:
2001–2004 Toyota Tacoma
Compatible with 1996–2000 Tacomas (fitment not confirmed; may require frame trimming)
Notes:
DIY bumper kit requires welding and finishing. Not winch-compatible. Includes 3/4" spacers and extended M12 hardware for Tacoma installation. For 1998–2000 models, trimming 2" from frame horns may be necessary. Not compatible with body lifts without visible gap. Minor surface blemishes may be present from handling. For off-road use only.
